Swarovski tM 35.2 Thermal Viewer And Clip-On Unit

The tM 35.2 impresses as both a clip-on and a hand-held observation device. At twilight and in darkness, you can easily rely on this thermal imaging device that is ready for use at any time throughout the night thanks to the energy-saving SWAROLIGHT automatic power on/off timer and intelligent brightness adjustment. Its intuitive handling makes the tM 35.2 a top choice for hunting enthusiasts. Instantly transform not only your SWAROVSKI OPTIK rifle scope from the dS, Z8i, Z6i, Z5(i), and Z3 series into a thermal imaging rifle scope with the compatible tMA thermal monocular adapter, but other brand optics too. tM 35.2 – the ideal thermal imaging clip-on device for dark nights at the hide.

OBJECTIVE

• Field of view - 10.9x8.7 m/100m
• Field of view with eye glasses - 100 % (°)
• Exit pupil distance (4x magnification) - 21 mm
• Optical magnification - 1x
• Digital magnification - 4x
• Objective lens - 35 mm/f1.0

SIZE AND WEIGHT

• Length in mm - 170 mm
• Width in mm - 54 mm
• Height in mm - 80 mm
• Weight - 495 g
• Connection thread - M44x0.75

ENVIRONMENT & CONDITIONS

• Functional temperature  -20 to +50 °C
• Storage temperature  -30 to +70 °C
• IP Protection class - IP68

DIGITAL

• Refresh rate (Hz) - 60Hz
• Screen type - AMOLED
• Screen resolution (pixels) - 2560x2048
• Sensor type - Uncooled VOx microbolometer
• Sensor resolution (pixels) - 320x256
• Pixel size (µm) - 12
• Start up time (s) - 2.5 s
• Battery - Li-lon 3000 mAh
• Battery operating time - 9 h
